Devridaimli Su Ürünleri Yetiştirme Sistemleri için DC HDPE Biyoçip
Shanghai Decycle New Materials Co., Ltd. specialises in the manufacture of MBBR media, suitable for applications in municipal and industrial wastewater treatment, as well as recirculating aquaculture systems.
Our MBBR media is manufactured entirely from brand-new polyethylene, featuring uniform and regular cavities and consistent dimensions. With a service life exceeding 15 years and meeting food-grade standards, it does not leach any toxic substances or plastic residues, ensuring there is no secondary contamination of the biological treatment tanks. Whether for wastewater treatment or recirculating aquaculture systems, Decycle can help you obtain MBBR media that delivers outstanding performance, is cost-effective and has a long service life.
Açıklama
DC BIOCHIP FOR RAS AND WWTP
Shanghai Decycle New Materials Co., Ltd. specialises in the manufacture of MBBR medya, suitable for applications in municipal and industrial wastewater treatment, as well as recirculating aquaculture systems.
Our MBBR media is manufactured entirely from brand-new polyethylene, featuring uniform and regular cavities and consistent dimensions. With a service life exceeding 15 years and meeting food-grade standards, it does not leach any toxic substances or plastic residues, ensuring there is no secondary contamination of the biological treatment tanks. Whether for wastewater treatment or recirculating aquaculture systems, Decycle can help you obtain MBBR media that delivers outstanding performance, is cost-effective and has a long service life.
DC BIOCHIP FOR RAS AND WWTP
DC BIOCHIP, su ve atık su arıtımında biyolojik süreçleri geliştirmek üzere tasarlanmış, son teknoloji ürünü bir biyofilm taşıyıcısıdır. Başlıca, çeşitli biyolojik arıtma uygulamalarındaki verimlilikleriyle bilinen Hareketli Yataklı Biyofilm Reaktörü (MBBR) ve Entegre Sabit Film Aktif Çamur (IFAS) sistemlerinde kullanılır. BioChip'in çalışma prensibi, özel mikroorganizmaların yerleşip çoğalabileceği geniş ve korumalı bir yüzey alanı sağlayarak biyofilm adı verilen biyolojik olarak aktif bir tabaka oluşturmasını içerir. Bu biyofilm daha sonra atık sudaki kirleticileri doğal olarak parçalar.
BioChip tasarımının ayırt edici bir özelliği "korunmuş aktif yüzey alanı"dır. Bu, yalnızca toplam yüzey alanının bir ölçüsü değil, aynı zamanda mikrobiyal kolonizasyonun güvence altına alındığı iç gözenek sistemini de ifade eder. Bu tasarım, çalkalanmış MBBR sistemlerinin doğasında bulunan mekanik darbelere ve kesme kuvvetlerine karşı gelişmiş mikrobiyal stabilite ve dayanıklılık sağlar. Taşıyıcının gözenekleri içindeki biyokütlenin sağlam koruması, biyofilm ayrılmasını en aza indirerek daha tutarlı ve güvenilir bir biyolojik arıtma performansı sağlar. Bu durum, biyofilmin yıkanmaya daha yatkın olduğu ve potansiyel olarak proses istikrarsızlığına yol açabildiği geleneksel taşıyıcılarla çelişir. Bu korumalı ortamın sağladığı doğal stabilite, doğrudan azaltılmış operasyonel risklere ve daha düşük bakım gereksinimlerine dönüşerek genel sistem verimliliğine ve güvenilirliğine katkıda bulunur.
Does your project require suitable MBBR media?
Please provide details of your application, inlet and outlet water standards, and tank capacity. For aquaculture clients, please also provide the stocking density, volume of aquaculture water, feeding rate, daily feed intake and protein content. Decycle can recommend the most suitable MBBR media for your project.
Bir teklif isteğiKey Features of DC BIOCHIP MBBR Media
1. Ultra-High Specific Surface Area
With a specific surface area as high as 5,500 m²/m³, it provides more attachment space for microorganisms, thereby increasing the system’s effective biomass.
2. Kararlı Biyofilm Oluşumu
The flake-like structure promotes biofilm formation and retention, contributing to long-term, stable system operation.
3. High Mass Transfer Efficiency
Studies and biofilm mass transfer principles indicate that a biofilm thickness of around 0.5 mm is often considered an optimal range for effective oxygen and substrate transfer. At this thickness, oxygen and pollutants can penetrate into the biofilm more efficiently, helping microorganisms maintain high biological activity.
DC BIOCHIP provides excellent attachment surfaces on both sides of the carrier, allowing biofilm to grow within a more controlled and efficient thickness range. This helps oxygen and nutrients reach different biofilm layers, ensuring that microorganisms inside the biofilm remain active.
4. Excellent Fluidization Effect
The density of DC BIOCHIP before biofilm formation is 0.95±0.02 g/cm³, which is close to the density of water. Under aeration or water flow, the media remains well suspended and fluidized in the reaction tank and does not settle easily. Adequate fluidization enhances contact between the media, wastewater, dissolved oxygen, and microorganisms, thereby improving biological treatment efficiency and ensuring stable system operation.
5. New PE Material
Made from White Virgin PE, it is corrosion- and aging-resistant, making it suitable for long-term use in wastewater treatment and recirculating aquaculture systems.
6. Uzun Hizmet Ömrü
With a service life of up to 15 years or more, it reduces replacement frequency and long-term maintenance costs.
7. Flexible Filling Rate
The filling rate ranges from 15% to 65% and can be flexibly designed according to different water qualities, treatment capacities, and project requirements.
8. Suitable for Nitrification and Ammonia-Nitrogen Removal
It provides an optimal attachment environment for nitrifying bacteria, making it suitable for ammonia-nitrogen control in municipal wastewater, industrial wastewater, and RAS aquaculture water.
9. Saves Tank Space
It increases microbial concentration within a limited tank volume, making it suitable for compact wastewater treatment systems and capacity expansion projects at existing wastewater treatment plants.
Teknik özellikler
| Parametre | Özellikler | birim | Uyarılar |
|---|---|---|---|
| Model | DC BİYOÇİP | - | Endüstri standardı geometri |
| Malzeme | Yüksek Yoğunluklu Polietilen (HDPE) | - | UV ışınlarına dayanıklı, gıda sınıfı |
| Renk | beyaz | - | Standart |
| Shape | Yuvarlak, Koruyucu Dış Halkalı Paraboloid | - | Optimize edilmiş akış ve biyofilm koruması |
| Çap (Ø) | 30 | mm | Nominal boyut |
| Yükseklik (lH) | 1.1 | mm | - |
| Belirli yüzey alanı | >5500 m²/m³ | - | - |
| Bireysel Medya Yoğunluğu | 0.95±0.02 g/cm³ | g / cm | - |
| Çalışma sıcaklığı | 5 - 60 | ° C | RAS koşullarına uygundur |
| servis Ömrü | > 15 | yıl | - |
Tipik uygulamalar şunlardır:
● Municipal wastewater treatment plants
● Industrial wastewater treatment
● Landfill leachate treatment
● Wastewater treatment in the oil refining, chemical, and food and beverage industries
● Wastewater treatment for hotels, resorts, and residential communities
● Wastewater treatment for schools, hospitals, and industrial parks
● Upgrades and expansions of existing wastewater treatment plants
● Recirculating aquaculture systems (RAS)
● Biological filters for fish farms
● Aquaculture of salmon, trout, tilapia, and shrimp
● Ammonia-nitrogen removal systems for fish hatcheries
Are you looking for an MBBR MEIDA supplier?
Decycle offers product model recommendations, bespoke manufacturing, packaging options and export services to importers, traders, wastewater treatment design firms and recirculating aquaculture system design firms.
Bir teklif isteğiSıkça Sorulan Sorular
S: Bir ticaret şirketi veya üreticisi misiniz?
C: fabrika bulunmaktadır.
S: teslim süresi ne kadardır?
C: Malların stokta olması genellikle 10-20 gündür. veya mallar stokta yoksa 30-45 gündür, miktarına göre değişir.
S: Örnek veriyor musunuz? ücretsiz mi yoksa ekstra mı?
A: Evet, numuneyi ücretsiz olarak sunabiliriz, alıcı tarafından ödenmesi gereken bir teslimat maliyeti vardır.
S: Ödeme şartlarınız nedir?
A: T/TL/C.
MBBR MEDIA from Decycle
If you are looking for a reliable MBBR MEDIA manufacturer offering moulding support, customised packaging, and application-focused advice on models and usage quantities, Decycle is ready to assist you.
Please contact us to discuss your application, specific model requirements and quantity needs. We will help you develop a more competitive solution.
